Cast Iron Valves & Boiler Mountings

Fabricated using supreme quality raw material, these offered valves comply with the defined parameters of the industry. Furthermore, keeping in mind the multifarious demands of the clients, we are presenting this gamut in different specifications.

Features:

Right angle pattern
Outside screw & yoke type rising stem
Body & bonnet: Cast steel as per ASTM A 216 Gr. WCB
Type of seat & disc : Renewable
Trim: Stainless steel (AISI 410)
Pressure rating: PN 40
Hydraulic test pressure: Body 76.0 kg/cm² , Seat 50.6 kg/cm²
Working temperature: Max. 425⁰C
End details: Flanged ends as per DIN 2545 raised face.

Features:

Bolted Cover
Type of seat & disc: Renewable
Trim: Stainless Steel (AISI 410)
Pressure rating: Class 150
Hydraulic test pressure: Body 30 kg/cm2 , seat 22kg/cm²
Working pressure: Max. BOP 10.54 kg/cm²
Working temperature: Max. 260 C
End details: Flanged ends as per ANSI B 16.5 C.L 150 R.F.

Features:

Right angle pattern
Outside screw & yoke type rising stem
Body & bonnet: Cast steel as per ASTM A 216 Gr. WCB
Type of seat & disc : Renewable
Trim: Stainless steel (AISI 410)
Pressure rating: PN 40
Hydraulic test pressure: Body 76.0 kg/cm² , Seat 50.6 kg/cm²
Working temperature: Max. 425⁰C
End details: Flanged ends as per DIN 2545 raised face.

Features:

Bolted Cover
S.S 410 Renewable working parts
Straight pattern
Design standard BS 5160 / DIN 2401
Flanged ends as per DIN 2545 R.F
Hydraulic Test Pressure: Body 76 k/cm2, seat 38 kg/cm2
Pressure Rating : PN 40
Bar Maximum working temperature: 425⁰

Features:

Bolted Bonnet
Outside Screw
Yoke type & rising stem with backseat arrangement
S.S 410 renewable working parts
Hand-wheel operated
Straight pattern
Design standard BS 5160
DIN 2401 flanged ends as per DIN 2545 R.F,/ BS 4504 Part-1

Features:

Bolted Cover
S.S 410 Renewable working parts
Straight Pattern
Flanged ends as per DIN 2533 RF for PN-16 sizes upto 150mm
DIN 2532 RF PN-10 for 20Omm

Features:

Bolted cover
Right angle pattern
Body & bonnet: Cast steel as per ASTM A 216 Gr. WCB
Type of seat & disc: Renewable
Trim: Stainless steel (AISI 410)
Pressure rating: PN 40
Hydraulic test pressure: Body 76.0 kg/cm^{2 ,} seat 50.6 kg/cm²
Working temperature: Max.4250⁰C
End details: Flanged ends as per DIN 2545 raised face.

Features:

Bolted cover
Body & bonnet: Cast steel as per ASTM A 216 Gr. WCB
Type of seat & Disc: Renewable
Trim: Stainless steel (AISI 410)
Pressure Rating: PN 40
Hydraulic test pressure: Body 76.0 kg/cm² , Seat 50.6 kg/cm²
Working temperature: Max.425⁰C
End details: Flanged ends as per DIN 2545 raised face

Features:

Outside screw & yoke type rising stem
Body & bonnet: Cast steel as per ASTM A 216 Gr. WCB
Type of seat & disc: Renewable
Trim: Stainless steel (AISI 410)
Pressure rating: PN 40
Hydraulic test pressure: Body 76.0 kg/cm², Seat 50.6 kg/cm²
Working temperature: Max. 425⁰C
End details: Flanged ends as per DIN 2545 raised face.

Featured Project

We keep the water flowing smoothly for you

Cast Steel Valves & Boiler Mountings

Durable cast steel valves built for high-pressure applications.

Bronze Valves & Boiler Mountings

Corrosion-resistant valves for steam and marine-based systems.

SG Iron Valves for Water Line

Strong and efficient valves ideal for water flow management.

Get Expert Advice with a Free Consultation!

Ultrices quam mattis posuere porttitor tellus rhoncus tristique. Primis aliquam dignissim interdum vel suscipit sodales.

Cast Iron Valves and Boiler Mountings old

Start the conversation to established good relationship and business.

Cast Iron Valves & Boiler Mountings

25 Mm Cast Steel Angle Globe Valve

Cast Steel Swing Check Valve

Cast Steel Angle Globe Valve

200 Mm Cast Steel Horizontal Lift Check Valve

32 Mm Cast Steel Angle Lift Check Valve

PV-201 Cast Steel Globe Valve

25 Mm Cast Steel Angle Lift Check Valve

100 Mm Cast Steel Horizontal Lift Check Valve

100 Mm Cast Steel Globe Valve
